特点

  • 业内较小尺寸及功耗
  • 全 TEFLON 接液材料
  • 最高耐压 100psi
  • 2通 NC\NO 可选
  • 孔径尺寸 1mm~3mm 可选
  • 零死区，低残留
  • 快速响应
  • 客户定制设计
  • 阀组结构可选

Standard 2-way Normally Closed

Part Number VDC PSI Orifice Body Poppet
161K011 12vdc 30 0.020" PCTFE PTFE
161K012 24vdc 30 0.020" PCTFE PTFE
161T010 6vdc 30 0.020" PCTFE PTFE
161T011 12vdc 30 0.020" PCTFE PTFE
161T012 24vdc 30 0.020" PCTFE PTFE
161T013 115vac 30 0.020" PCTFE PTFE
161T014 9vdc 30 0.020" PCTFE PTFE
HP161T012 24vdc 100 0.020" PCTFE PTFE
22S011 12vdc 30 0.062" PCTFE PTFE
22S012 24vdc 30 0.062" PCTFE PTFE
22S013 115vac 30 0.062" PCTFE PTFE
22SPP011 12vdc 30 0.062" PEEK PTFE
22SPP012 24vdc 30 0.062" PEEK PTFE
22T010 6vdc 30 0.062" PCTFE PTFE
22T011 12vdc 30 0.062" PCTFE PTFE
22T012 24vdc 30 0.062" PCTFE PTFE
22T013 115vac 30 0.062" PCTFE PTFE
T22S011 12vdc 30 0.062" PCTFE PTFE
T22S012 24vdc 30 0.062" PCTFE PTFE
T22SPP011 12vdc 30 0.062" PEEK PTFE
T22SPP012 24vdc 30 0.062" PEEK PTFE
HPK2S011 12vdc 100 0.062" PCTFE PTFE
HPK2S012 24vdc 100 0.062" PCTFE PTFE
HPK2ST011 12vdc 100 0.062" PCTFE PTFE
HPK2ST012 24vdc 100 0.062" PCTFE PTFE
HPPP011 12vdc 100 0.062" PEEK PTFE
HPPP012 24vdc 100 0.062" PEEK PTFE
36T011 12vdc 30 0.125" PCTFE PTFE
36T012 24vdc 30 0.125" PCTFE PTFE
36T013 115vac 30 0.125" PCTFE PTFE
HP36T011 12vdc 100 0.125" PCTFE PTFE
HP36T012 24vdc 100 0.125" PCTFE PTFE

Standard 2-way Normally Open

Part Number VDC PSI Orifice Body Poppet
161T021 12vdc 30 0.062" PCTFE PTFE
161T022 24vdc 30 0.062" PCTFE PTFE
161T023 115vac 30 0.062" PCTFE PTFE
22T021 12vdc 30 0.062" PCTFE PTFE
22T022 24vdc 30 0.062" PCTFE PTFE
22T023 115vac 30 0.062" PCTFE PTFE
HP22T021 12vdc 100 0.062" PCTFE PTFE
HP22T022 24vdc 100 0.062" PCTFE PTFE
36T021 12vdc 30 0.156" PCTFE PTFE
36T022 24vdc 30 0.156" PCTFE PTFE
36T023 115vac 30 0.156" PCTFE PTFE
64T021 12vdc 30 0.156" NPT PTFE
64T022 24vdc 30 0.156" NPT PTFE
64T023 115vac 30 0.156" NPT PTFE
HP64T022 24vdc 100 0.156" NPT PTFE
